MDC Diesel S300 69/73/14cm 2003-07 Cummins 5.9l Drop In Turbocharger

MDC Diesel S300 69/73/14cm 2003-07 Cummins 5.9l Drop In Turbocharger

Regular price $1,299.00 USD
Regular price Sale price $1,299.00 USD
Sale Sold out
Shipping calculated at checkout.
Thrust Bearing

S369/73/14CM or 12CM Direct Bolt Turbocharger for 03-07 5.9l Cummins.


MDC Diesel S300 69mm Cummins drop in replacement turbo for the 03 to 07 5.9l Cummins. This S369/73 Cummins Direct Bolt in Turbo Is equipped with a large shaft and heavy duty bearings for superior durability and performance.

This turbo is rated for 750 horsepower, is a great power maker on 2003, 2004, 2005, 2006 and 2007 5.9l Cummins Turbo diesels.

Wheel Dimensions:
Compressor: 69 mm with Extended Tip Technology.
Turbine: 73 mm exducer. Cast in Inconel 713 for high-temperature resistance.

Twin Scroll Divided T3 Gated Housing 14cm .80 A/R or 12CM .70 A/R.
Waste Gate set to 40psi and is user adjustable.

This Cummins Direct Bolt in Turbo Is a great upgrade to the stock HE351 or HE341 turbo that comes factory on the 03-07 5.9l Cummins.


2 M10-1.5X35mm Bolts required for install, not included

Specifications:
  • S300 Frame, Large 8mm Shaft
  • 64.5mm Compressor wheel Inducer
  • 68 or 73mm Turbine Wheel
  • Standard Brass 270 Degree Thrust OR Extreme Duty Steel 360* Thrust
  • 12cm or 14cm GATED Turbine Housing
  • Direct fit for 2003-2007 Cummins 5.9l Trucks
THIS TURBO IS EXCELLENT FOR DAILY DRIVING, RACING AND SLED PULLING 750HP. NOT IDEAL FOR TOWING.
